For heavy duty floors
avoids dirt accumulation, fast cleaning
ensures good skid resistance
hard wearing, maintenance-free, long lasting
absorbs movement in 3 directions
| Standard version | Joint width max. [mm] | Total movement [mm] | Joint width visible [mm] | Total width [mm] | Joint height [mm] | Load bearing capacity lorris (DIN 1072) [kN] | Load bearing capacity forklift trucks acc. (DIN 1055) [kN] | Load bearing capacity special vehicles with solid plastic tyres [kg/mm] |
|---|---|---|---|---|---|---|---|---|
| FS 135/25 | 35 | 20 (±10) | 135 | 206 | 25 | 600 | 250 | 30 |
| FS 174/25 | 70 | 20 (±10) | 174 | 245 | 25 | 600 | 130 | 15 |
Production length: 4 m
Standard colour: Aluminium
We recommend installation using epoxy adhesive
